Innovative OCT & OCTA products
Optovue iseries portfolio
The Optovue iseries product portfolio includes the iVue80, iFusion80, iScan80 & SOLIX.
Continuing to push the frontiers of OCT innovation and ophthalmic medical diagnostic imaging, the iseries systems offer a simple and intuitive user experience, coupled with advanced OCT technology.
Compare our products
| iScan80 | iFusion80 | iVue80 | |
|---|---|---|---|
| Scanner | |||
| Depth resolution (in tissue) (um) | 5 | 5 | 5 |
| OCT Image A-scan / second | 80,000 | 80,000 | 80,000 |
| Transverse resolution (um) | 15 (retina) | 15 (retina) | 15 (retina) |
| Scan range | |||
| Depth (mm / inch) | 2 to 2.3 mm / 0.079 to 0.09 inches (retina) | 4 to 2.3 mm / 0.079 to 0.09 inches (retina) | 3 to 2.3 mm / 0.079 to 0.09 inches (retina) |
| Scan beam wavelength (nm) | 840 (+/-10) | 840 (+/-10) | 840 (+/-10) |
| OCT Fundus Image face | |||
| FOV | (H) 21° x (V) 21° | 12 (H) x 9 (V) / 0.47 mm(H) x 0.35 mm(V) / 0.47 (H) x 0.35 (V) 0.018 (H) x 0.014 (V) | 12 (H) x 9 (V) / 0.47 mm(H) x 0.35 mm(V) / 0.47 (H) x 0.35 (V) 0.018 (H) x 0.014 (V) |
| Minimum pupil diameter (mm / inch) | 2 mm / 0.079 inches | 2 mm / 0.079 inches | 2 mm / 0.079 inches |
| External image (Live IR) FOV (mm / inch) | 13 x 8 mm / 0.51 x 0.31 inches | FOV 13 x 9 mm / 0.51 x 0.35 inches | FOV 13 x 9 mm / 0.51 x 0.35 inches |
| Dimensions | |||
| Dimensions (mm / inch) | (W) 50.31 x (L) 40.2 x (H) 45.26 cm / (W) 19.81 x (L) 15.83 x (H) 17.82 inches | (W) 48.5 x (L) 87.37 (H) 668 to 871.22 cm / (W) 19.1 x (L) 34.4 x (H) 263-343 inches | (W) 48.5 x (L) 87.37 (H) 668 to 871.22 cm / (W) 19.1 x (L) 34.4 x (H) 263-343 inches |
| Weight (kg / lbs) | 19.48 kg / 42,94 lbs | 72.57 kg / 160 lbs | 35.83 kg / 79 lbs |
| Computer/networking specifications | |||
| Operating system | Win 10 - 64 bit | Win 10 - 64 bit | Win 10 - 64 bit |
| Processor speed | Intel® Celeron (i7-8700T 2.40 GHz) | 3.0 GHz; Intel Quad Core (desktop); Core 2 (laptop) | 3.0 GHz; Intel Quad Core (desktop); Core 2 (laptop) |
| Network bandwidth | 1 Gbps or higher | 1 Gbps or higher | 1 Gbps or higher |
| Computer RAM | 16 GB or higher | 4 GB or higher | 4 GB or higher |
| Monitor resolution | 24 in.1920x1080 60Hz | 1920 x 1080 at 32-bit | 1920 x 1080 at 32-bit |
| DICOM compatible | yes | yes | yes |
| Acquisition | |||
| Self guiding | yes | − | − |
| Speaks to patients | yes | − | − |
| Fundus imaging | |||
| Field angle | − | 45° | − |
| Image | − | 5.2 Million Pixels | − |
| Pupil diameter | − | ≥4 mm / ≥0.157 inches | − |
| Illumination during alignment to patient’s eye | − | NIR LED | − |
| Flash for retina image capture | − | White LED | − |
| Cornea image | − | Illumination from 3 external white LED sources in steady state mode | − |
| Total focus diopter adjustment range | − | -35D to +30D | − |
| Z-ranging (Working Distance) (mm / inch) | − | -25 mm / -0.98 inches | − |
| Fixation | − | 6 Internal & one Adjustable External | − |
| Focus adjustment | − | Manual | − |
| Scans | |||
| 3D disc | ● | ● | ● |
| 3D retina | ● | ● | ● |
| Corneal angle and vault mapping | ● | ● | ● |
| Corneal pachymetry and epithlium thickness | ● | ● | ● |
| iWellness | ● | ● | ● |
| Nerve fiber GCC map | ● | ● | ● |
| ONH scan | ● | ● | ● |
| Retina radial line | − | ● | ● |
| Retinal cross line | ● | − | − |
| Retinal map | ● | ● | ● |
● standard | ○ optional | − not available | □ not recommended
